Shielded Power Inductors MLC7532-101NE / MLC7532-221ME / MLC7540-102ME / MLC7540-142ME
Shielded Power Inductors MLC7532-101NE / MLC7532-221ME / MLC7540-102ME / MLC7540-142ME
Characteristics
- Exceptionally low DC resistance
Soft saturation for high peak current handling
Magnetic shielding for high-density packaging
Ideal for low-voltage, high-current DC-DC converters and VRD/VRM controllers
AEC-Q200 Grade 3 (−40°C to +85°C)
Electrical Properties:
| Part number |
Inductance (µH) |
DCR typ (mOhms) |
DCR max (mOhms) |
SRF typ (MHz) |
Isat (A) 10% drop |
Isat (A) 20% drop |
Isat (A) 30% drop |
Irms (A) 20°C rise |
Irms (A) 40°C rise |
| MLC7532-101NE_ |
0.10±30% |
1.20 |
1.40 |
140 |
21.0 |
38.0 |
56.2 |
24.9 |
32.5 |
| MLC7532-221ME_ |
0.22±20% |
2.50 |
2.80 |
128 |
22.9 |
41.0 |
59.2 |
20.2 |
26.5 |
| MLC7542-311ME_ |
0.31±20% |
2.30 |
2.70 |
114 |
12.2 |
21.9 |
29.8 |
20.0 |
23.8 |
| MLC7542-601ME_ |
0.60±20% |
2.95 |
3.80 |
96 |
9.9 |
15.7 |
20.2 |
16.7 |
21.9 |
| MLC7540-102ME_ |
1.00±20% |
4.42 |
5.00 |
81 |
7.4 |
11.3 |
15.7 |
13.8 |
18.2 |
| MLC7540-142ME_ |
1.40±20% |
7.10 |
8.00 |
76 |
6.3 |
11.0 |
14.3 |
10.6 |
14.1 |
| MLC7540-222ME_ |
2.17±20% |
11.7 |
13.0 |
65 |
5.3 |
8.3 |
11.4 |
8.5 |
11.3 |
Shape and Dimensions:
Product picture:
Shielded Power Inductors MLC7532-101NE / MLC7532-221ME / MLC7540-102ME / MLC7540-142ME
